PRODUCT ADVANTAGES
●Teaching-Free, Programming-Free,
●Can input 3D drawing (format .STP, IFC, IGES .... ) from Tekla, NX, Autodesk Revit, Fusion 360, CATIA, SolidWorks·····
●Automatic extract welding seams
●Built-in expert welding process library
●Automatic generate tool path and welding program
By adding a seventh axis with synchronized robot and track motion control, the working area is significantly expanded.
Work areas can be set up on both sides of the track, or arranged in segments for small-part welding. Welding and handling can be carried out simultaneously, effectively enhancing production efficiency.
WORKPIECE
Suitable for open-type components, such as H-beams, roof beams, box columns, and certain ship small assemblies with fillet welds.
TECHNICAL PARAMETERS
Item | Parameter Range | Unit | Remarks |
Equipment Model | KDDG0012-01 | / | / |
Number of Axis | 7 | / | Can be equipped with 2 dual-axis positioners |
Required Ambient Temperature | -10~45 | ℃ | / |
Maximum End Load | 6 | kg | / |
Working Range (Recommended) | W2200*L12000*H500 | mm | / |
Peak Total Machine Power | 37 | kW | / |
Rated Input Voltage | 380±10% | V | Three-phase |
Rated Input Frequency | 50 | Hz | / |
Footprint | 3000*15000 | mm | / |
The software is user-friendly, enabling operators to get started with just 1-2 days of training. Once the workpiece is set up, the process is fully automated, significantly reducing the need for operator skill.
|
|
